Hydraulic Gooseneck Low Bed Trailer
- High-Capacity Custom Solutions - Our hydraulic gooseneck low bed trailers offer 60+ ton load capacity with fully customizable dimen……
Product Description
- High-Capacity Custom Solutions - Our hydraulic gooseneck low bed trailers offer 60+ ton load capacity with fully customizable dimensions and configurations to match your specific heavy haul requirements.
- Industry-Leading Expertise - As China's premier trailer manufacturer with over 40 years of experience since 1982, we deliver proven reliability for demanding transport operations.
- Global Logistics Ready - We support worldwide delivery through both RO-RO and bulk shipping options, ensuring cost-effective transportation to your job site.
- Advanced Hydraulic System - Features our heavy-duty hydraulic gooseneck mechanism for superior load balancing and easy height adjustment during loading/unloading operations.
| Weight: | Tare Weight | 12T |
| Loading capacity | 60 T | |
| Total weight | 72 T | |
| Dimensions: | Outside dimension | 13000*3000*3180 mm (The final dimensions depend on the final design drawings) |
| Type | Gooseneck | Hydraulic gooseneck |
| Frame: | Design/welding technology | Heavy duty and extra durability designed;welding by automatic Submerged-Arc processes. |
| Main beam | Opting for high strength Q345B steel, 520mm deep welded I-section main beams Top Flange thickness 20mm, width 140mm; Bottom Flange thickness 25mm, width 140mm.Middle Flange thickness 12mm; | |
| Cross beam | Heavy duty Special U steel | |
| Side beam | 250mm high I beam | |
| Floor | 5 mm thickness chequer plate | |
| Front ladder (ramps) | Two pieces | |
| OEM parts: | Axle | 3 *13T capacity, FUWA brand (Chinese best brand) |
| King Pin | 2.00’’/3.5’’ bolting king pin, JOST brand | |
| Suspension | Heavy duty undermount suspension with equalizers, American design (high-strength type) | |
| Steel Spring | 10pcs leaf spring, 13mm thickness, 90mm width | |
| Landing legs | JOST brand, manual operation landing legs with sand shoe | |
| Tire specs | 315/80R22.5., Triangle brand (Chinese famous brand) | |
| Rim | 9.0-22.5(Chinese famous brand) | |
| Number of wheel | 13 pieces(including one spare wheel) | |
| Brake system | WABCO relay valve; Four double and two single brake chamber; Two units of ISO standard coppery air-connector. | |
| ABS system | Without（Can be choose freely,450 USD/set） | |
| Electrical: | One unit of 24V 7-pin ISO 1185 socket; LED lights | |
| Miscellaneous: | Painting | color advised by client |
| Marking | Standard | |
| Side Guard | Standard | |
| Spare Tire Carriers | Two set of heavy duty spare wheel carriers | |
| Tools box | One piece (1. 0*0. 5*0. 5m), under the goose neck(with 1 Tire spanner,1 gudgeon sleeve and 1 cranking bar) | |
| Note: All the details not mentioned will design as the final confirmation with the customer | ||
In consideration of our customers are from different countries, and their government have different road safety rules and regulations, so the specifications of our low bed trailer is different too, as an manufacturer,we can design the trailers according to the different requirements.
