Semi Flatbed Trailer
- Tongya Semi Flatbed Trailer – Reliable Hauling for Demanding Loads Engineered for secure, high-capacity transportation, Tongya’s semi ……
Product Description
Tongya Semi Flatbed Trailer – Reliable Hauling for Demanding Loads
Engineered for secure, high-capacity transportation, Tongya’s semi flatbed trailer is the ideal solution for construction equipment, steel coils, timber, and industrial machinery. Built with reinforced steel framing and a non-slip deck, it delivers durability, stability, and loading flexibility for heavy logistics operations.
Specification:
| Manufacturer | Tongya Automobile CO., LTD. |
| Tare Weight | Approx. 7.3 T |
| Dimension | 12500*2500*1550mm |
| Loading Capacity | 40t |
| Axle | 13T, 3axles, Fuwa brand |
| Rim | 9.00*22.5 |
| Tire | 12R22.5, 13PCS Triangle brand |
| Suspension | Mechanical suspension |
| Leaf Spring | 90(width)mm*13(thickness)mm*10 layer(especial for exporting market) |
| King pin | 2.0 or 3.5inch JOST brand |
| Main beam | Height is 500mm, material is Q345B steel |
| Side beam | 16mm channel steel (Material is Q235B steel) |
| Bottom Platform | 3mm checquered steel plate |
| Twist lock | 12PCS |
| Brake chamber | Wabco re 6 relay valve; T30/30+T30 spring brake chamber; two units of 45L air tanks |
| ABS | Optional |
| Valve | Wabco valve (especial for exporting market) |
| Light | LED Light (especial for exporting market) |
| Voltage | 24V |
| Receptacle | 7 ways (7 wire harness) |
| Tool box | One piece 1m *0.5m*0.5m ( size can be customized) |
| Painting | Spray powder |
| Shipping terms | By bulk vessel, RORO, or 40HQ container |
| Any parts fitted could according to clients request, contact us to get more. | |
